| Material Name | PVC (Polyvinyl chloride) |
| Characteristics | PVC options include soft and hard varieties which can be used together. High temperature resistant, matching national pharmacopoeia index requirements. |
| PP Tube Dimensions | Inner Diameter: 0.3mm~19.50mm; Wall Thickness: 0.50mm; Deviation: ±0.02mm~±0.150mm |
| Alternative Material | Medical grade (USP Class VI); Food grade (FDA) and Industrial Grade options available. |
| Extra Value Service | Customizable tube colors; Baso4 addition (20~40%) for X-ray development; transparent or frost finishes. |
| Application Range | Stomach tubes, oxygen catheters, infusion catheters, pressure extension tubes, force pump connector tubes, trachea cannula catheters. |
| Properties | HDPE | LDPE | PA12 | PEBAX | TPU | PP |
| Density | 0.96 | 0.93 | 1.15 | 1.01 | 1.2-1.25 | 0.88 |
| Rigidity | 60D-65D | 48D-53D | 68D-70D | 23D-72D | 60A-75D | 60-69D |
| Max Temp | 54ºC | 54ºC | 80ºC | 80ºC | 80~100ºC | 80~100ºC |
| Tenacity | Common | Good | Common | Common | Excellent | Common |
| Biocompatibility | Good | Good | Excellent | Excellent | Excellent | Good |
| Medical Grade | Yes | Yes | Yes | Yes | Yes | Yes |
We provide precision extrusion catheters, secondary operations, and custom-made services. Materials include TPU, PE, PP, PVC, Pebax, PA, PEEK, PSU, PPSU, PC, EVA, TPE, ABS, PCL, PLA, PTFE, FEP, and Silica.
